The Pironman 5 includes the Pi5 NVMe PIP (PCIe Peripheral Board), a PCIe adapter board specifically designed for NVMe solid-state drives. This board supports four sizes of NVMe SSDs: 2230, 2242, 2260, and 2280, all of which can be installed in an M.2 M key slot. The connection is certified for Gen 2.0 speeds (5 GT/sec), but can be forced to Gen 3.0 (10 GT/sec) for faster performance.
Compatible NVMe SSDs include:
ADATA Legend 700, 800, and XPG SX8200 Pro
Axe Memory Generic Drive
Crucial P2, P3, P3 Plus M.2
Inland PCIe NVMe SSD
KIOXIA EXCERIA and EXCERIA G2 NVMe SSD
Kingston KC3000, NV2
Lexar NM710, NM620
Netac NV3000, NV2000 NVMe SSD
Origin Inception TLC830 Pro NVMe SSD
Pineberry Pi Pinedrive (2280)
PNY CS1030
Sabrent Rocket 4.0, Rocket Nano
Samsung 970 EVO Plus, 980, 980 Pro
Team MP33
Western Digital SN850, SN740, SN570, SN530, and Black
SN750 SE (Phison Controller), and Blue SN550/SN580 series
(If you know how to install the latest rpi-eeprom updates, pieeprom-2024-01-24.bin fixed the Western Digital Blue SN550 nvme boot issue. For more information, visit
https://forums.raspberrypi.com/viewtopic.php?t=364327)XPG GAMMIX S70 BLADE, SX8200 Pro
